model:PT-T1200R-110IC

1200C Rotary Tilt Tube furnace

Application

Detailed Parameters Of The Product

Brief Introduction:
It’s a rotary tube furnace with alumina tube and 30 segments temperature controllers. It is an excellent furnace for sample annealing, diffusion and sintering in various gas atmosphere up to 1200°C.

The main features are as below:
1. Great temperature uniformity.
2. Over temperature protection and alarm.
3. PID automatic control via SCR power control.

Technical Parameter:

Model	KJ-T1200R-110IC
Furnace structure	LED
Max. Working temperature	1200℃
Continuous working Temperature	≤1100℃
Heating Rate	0-20℃/min, Suggestion 0~10℃/min
Temperature Zone	Single
Heating zone length	400mm
Tube size	Central part OD110mm,length 400mm both sides OD80mm, total length 1000mm
Heating Element	Resistance wire with Mo
Temperature Control Accuracy	±1℃
Tube rotating Speed	0 - 10RPM variable
Furnace tilt angle	0-30°
Thermocouple	K type
Max. Power	4.0KW
Tube material	Quartz tube
Chamber material	Alumina Fiber
Working Voltage	AC 220v, single phase, 50 Hz(or according to your requirement)
Temperature Controller	30 steps programmable PID digital controllers
Warranty	One year limited warranty (Consumable parts such as heating elements are not covered by the warranty)
