All products are customizable, leave message immediately, we will reply as soon as possible.
| Model | PT-T1400 |
| Display | LED (LCD Can be customized according to customer needs) |
| Max. Temperature | 1400℃ |
| Working Temperature | ≤1350℃ |
| Heating Rate | Suggestion 0~5℃/min (If diameter is big, pls control the rate as slow as possible) |
| Temperature Zone | 500 mm (1 hot zone) (Can be customized according to customer needs) |
| Temperature Control Accuracy | ±1℃ |
| Tube Size | Ф130mm x 1200mm ODxL (Can be customized according to customer needs) |
| Tube Material | Alumina tube |
| Tube sealing | One side of tube is with feeder The other side is with outlet |
| Heating Element | Sic heating elements |
| Tube Rotating Speed | 0-5 RPM |
| Furnace Tilt Angle | 0~5℃ |
| Thermocouple | S Type |
| Temperature Control | PID automatic control via SCR power control |
| Heating curves | 30 steps programmable |
| Chamber material | Alumina Fiber |
| Warranty | One year limited warranty (Consumable parts such as heating elements and alumina tube are covered by the warranty) |
