All products are customizable, leave message immediately, we will reply as soon as possible.
| Product Model | PT-T1300-L100X |
| Furnace structure | Double-layer shell structure, equipped with a cold air system to automatically cool the shell temperature to no more than 50°C |
| Maximum temperature | 1400℃ |
| Continuous operating temperature | ≤ 1300℃ |
| Heating rate | Recommended temperature ≤10℃/min, fastest heating rate 20℃/min |
| Furnace tube material | Corundum tube |
| Furnace tube size | Φ100mm * 1300mm Customizable |
| Heating zone length | 400mm Customizable |
| Temperature control system | The temperature control system adopts artificial intelligence regulation technology and has PID regulation and self-tuning functions. 1. Use PID method to adjust temperature control, and can set 30 sections of temperature rise and fall programs 2. Temperature control accuracy ± 1°C 3. With over-temperature protection and disconnection protection 4. The instrument has the function of temperature self-tuning |
| Heating elements | High temperature silicon carbon rod |
| Temperature measuring element | S -type thermocouple |
| Tilted structure | Can be tilted at an angle of 0-10° ( adjustable angle ) to facilitate loading and unloading |
| Rotating structure | It can rotate 360 degrees , with a speed of 3-6 revolutions ( adjustable speed ) so that the material is evenly heated in the furnace. |
| Feed silo | The feeding bin is a 2L stainless steel sealed tank with spiral feeding and adjustable feeding speed. |
| Discharge silo | The discharge bin is a 2L stainless steel square box |
