| Product Model | PT-M1200-L180 |
| Furnace structure | Double-layer shell structure, equipped with a cold air system to automatically cool the shell temperature to no more than 50°C |
| Furnace material | High-quality high-purity alumina polycrystalline fiber curing furnace formed by vacuum adsorption using Japanese technology, the material has good thermal insulation performance, high reflectivity and balanced temperature field |
| Maximum temperature | 1200℃ |
| Continuous operating temperature | ≤1100℃ |
| Heating rate | Recommended temperature ≤10℃/min, fastest heating rate 20℃/min |
| Crucible size | Φ130 *130mm (can be customized according to customer needs) |
| Temperature control system | The temperature control system adopts artificial intelligence regulation technology and has PID regulation and self-tuning functions. 1. Use PID method to adjust temperature control, and can set 30 sections of temperature rise and fall programs 2. Temperature control accuracy ± 1°C 3. With over-temperature protection and disconnection protection 4. The instrument has the function of temperature self-tuning |
| Heating elements | Alloy resistance wire |
| Temperature measuring element | N -type thermocouple |
| Crucible cover | 304 material, with four thermocouple seats, no need for sealing |
| Temperature measurement thermocouple | 4 N-type ceramic tube temperature measuring thermocouples are removable |
| Furnace structure | Vertical structure |
