Detailed Parameters Of The Product
Product Introduction: PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacPT-M1700-L220 pit type crucible furnace uses silicon molybdenum rods as heating elements, and the working temperature is up to 1600℃. The control system of this series of equipment is internationally leading, with the characteristics of safety and reliability, simple operation, high temperature control accuracy, good insulation effect, high furnace temperature uniformity, and the ability to evacuate the atmosphere. It is widely used in experiments and mass production in colleges and universities, scientific research institutes, industrial and mining enterprises, etc.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
It adopts a double-layer shell structure and an intelligent program temperature control system, phase-shift triggering, thyristor control, the furnace chamber is made of alumina polycrystalline fiber material, and the double-layer furnace shell is equipped with an air cooling system. The furnace has the advantages of balanced temperature field, low surface temperature, fast temperature rise and fall rate, and energy saving.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacMain technical requirements:PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac1、Maximum temperature: 1700℃PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2、Long-term use temperature: ≤1600℃PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3、Temperature control system: 30-segment programmable PID intelligent control, phase-shift triggerPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4、Furnace size: φ220*300mmPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5、Furnace structure: double-layer shell with built-in air cooling structurePbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Temperature control protection: With over-temperature, over-temperature, and broken protection functionsPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacMain functions and features:PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac1、The furnace chamber adopts high-quality alumina polycrystalline fiber inorganic material formed by vacuum adsorption using Japanese technology, which has good thermal insulation performance, durability, high tensile strength, no impurities, high purity, and energy-saving effect is significantly better than other domestic fiber materials;PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. The entire furnace body adopts a double-layer inner liner structure with an air gap in the middle. Even if the furnace temperature reaches the highest, the surface of the furnace body can still be safely touched without feeling hot.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. The furnace is made of energy-saving materials, and the energy consumption of the whole machine is only 1/3 of that of the same traditional electric furnace, which is energy-saving and environmentally friendly .PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. The furnace body is equipped with: output voltage and output current monitoring meters, and the heating status of the furnace is clear at a glance .PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5. Over-temperature alarm and power-off function, safe and reliable operation.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Main uses and scope of application:PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
This series of products are special heat treatment equipment developed for laboratories of colleges and universities, scientific research institutes and industrial and mining enterprises for debinding, sintering, melting, analysis and production of ceramics, metallurgy, electronics, glass, chemical industry, machinery, refractory materials, new material development, special materials, powder metallurgy , magnetic materials , building materials, metals, non-metals and other chemical materials.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacTechnical parameters:
| Product Model |
PT-M1700-L220 |
| Furnace structure |
Double-layer shell structure, equipped with a cold air system to automatically cool the shell temperature to no more than 50°C |
| Furnace material |
High-quality high-purity alumina polycrystalline fiber curing furnace formed by vacuum adsorption using Japanese technology, the material has good thermal insulation performance, high reflectivity and balanced temperature field |
| Maximum temperature |
1700 ℃ |
| Continuous operating temperature |
≤1600℃ |
| Heating rate |
Recommended temperature ≤10℃/min, fastest heating rate 20℃/min |
| Furnace size |
Φ220 *300mm Customizable |
| Crucible size |
Φ220mm Customizable |
| Temperature control system |
The temperature control system adopts artificial intelligence regulation technology and has PID regulation and self-tuning functions.PbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. Use PID method to adjust temperature control, and can set 30 sections of temperature rise and fall programsPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. Temperature control accuracy ± 1°CPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. With over-temperature protection and disconnection protectionPbTMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. The instrument has the function of temperature self-tuning |
| Heating elements |
High temperature silicon molybdenum rod |
| Temperature measuring element |
Type B double platinum-rhodium thermocouple |
| Furnace structure |
Vertical structure |
| Sealing flange |
Stainless steel double-layer water-cooled flange with electrode holes on the flange |
