All products are customizable, leave message immediately, we will reply as soon as possible.
| Model | PT-M1700 |
| Chamber mode | Side door |
| Display | Touch screen (LCD) |
| Maximum temperature | 1600 degrees Celsius |
| Operating temperature | <= 1500 degrees Celsius |
| Heating rate | It recommended 0~ 10 deg.] C / min |
| Temperature zone | single |
| Accuracy | + -1 degrees Celsius |
| Inner cavity size | 120 * 120 * 130 (mm) Customizable |
| Heating element | MoSi2 |
| Thermocouple | B Type |
| Temperature control | PID automatic control through SCR power control |
| Heating curve | 30 steps programmable |
| Cabinet material | Alumina fiber |
| Guarantee | One year limited warranty (for wearing parts, such as heating elements Not covered by warranty) |
