The PT-MZ1600-221LD is a white-cabinet, bottom-loading bell furnace engineered for high-temperature sintering up to 1600 °C. The fixed upper chamber and motorized lifting table allow the workpiece to be raised vertically into a 700 × 700 × 450 mm hot zone, giving unobstructed access from below. MoSi₂ heating elements and a Type B thermocouple ensure accurate, stable heating at 1400 °C continuous working temperature. The whole system is built into a ventilated white mobile cabinet with locking casters, touch-screen control, and a remote hand pendant for safe, repeatable operation.
| Product Name | Bottom-lift muffle furnace |
| Product Model | PT- MZ1600-221LD |
| Design temperature | 1600 ℃ |
| Long-term operating temperature | 1400 ℃ |
| Pallet vertical movement speed | per second , and the distance traveled is 450mm. |
| Weight of material heated each time | 2kg |
| Box color | black |
| Furnace size | 700*700*450mm (450mm is the height) |
| heating element | silicon molybdenum rod |
| heating rate | 10 ℃/min |
| thermocouple | B type |
| Temperature controller | touchscreen |
