Inclined rotary tube furnace
model:PT-1200TX

Inclined rotary tube furnace

    Application:  Widely used in experiments and small batch production in universities, scientific research institutes, industrial and mining enterprises, etc.
Contact us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product

Description:nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac

    Inclined rotary tube furnace is a high temperature reactor with special rotary and tilt function. It is specially designed for sintering of inorganic compound, such as, mineral particles and battery material and with better uniformity. Multi heating zone, condenser and tail gas collect equipment can be optional part according to different experiment. nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac

1.Features of Inclined rotary tube furnace :nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(1).
Rotary tube to keep uniform heating nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(2). Variable diameter tube to keep uniform heatingnNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(3). Programmable and PID automatic control nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(4). Metal key or touch panel operating interface for your optionnNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(5). Inputting protective gas or atmosphere is also possiblenNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2.Technical parameters of Inclined rotary tube furnace:
nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac

Model PT-1200TX
Limiting temperature 1200℃
Working temperature ≤1150℃
Heating rate Suggestion 0~20℃/min
Temperature zone Single
Temperature accuracy ±1℃
Tube size Φ60×1200(mm)
Heating element  electric wire with mo
Thermal couple K Type
Temperature control PID automatic control via SCR power control
Heating curves 30 steps programmable
Angle of inclination 0-15 degrees (Can be arbitrary adjustable)
Furnace tube rotation speed 0-20 r/min
Rated power 3KW
Working voltage 110-480V 50-60Hz
Warranty 12 month (exclusive wearing part)
Inclined rotary tube furnace
Inclined rotary tube furnace can be customized according to customers’requirements.nNnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!
