model:PT-V750
Aluminum brazing vacuum furnace
Application: Used for vacuum brazing of heat exchangers and electronic communication components used in automobiles, aircraft, ships, compressors, air separation equipment, household appliances, etc.
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters of the Product
dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacIntroduction:dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacThe heating chamber of the vacuum aluminum brazing furnace is heated by nickel-chromium belts and has a composite insulation structure with multiple layers of 1Cr18Ni9Ti reflective screens;dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The vacuum system is a three-stage high vacuum system consisting of a diffusion pump, a Roots pump, and a mechanical front pump;dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
All aluminum brazing furnaces are negative pressure furnaces, and external circulation air cooling systems can also be installed according to customer requirements;dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The size of the effective area can be customized according to customer needs;dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Computer control system;dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacdtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacApplication areas:dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacUsed for vacuum brazing of heat exchangers and electronic communication components used in automobiles, aircraft, ships, compressors, air separation equipment, household appliances, etc.dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacdtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacdtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacTechnical parameters: (customizable according to user requirements)：
| Model |
Effective heating area size(width * height * depth/mm） |
Maximum temperature（℃） |
Ultimate vacuum（pa） |
Temperature uniformity（℃）） |
Pressure rise rate（Pa/h） |
Loading capacity(kg) |
| PT-V750-12W |
200*200*300 |
750 |
6.67*10-3 |
±5 |
0.67 |
30 |
| PT-V750-36W |
300*300*400 |
750 |
6.67*10-3 |
±5 |
0.67 |
80 |
| PT-V750-96W |
400*400*600 |
750 |
6.67*10-3 |
±5 |
0.67 |
200 |
| PT-V750-175W |
500*500*700 |
750 |
6.67*10-3 |
±5 |
0.67 |
300 |
| PT-V750-324W |
600*600*900 |
750 |
6.67*10-3 |
±5 |
0.67 |
500 |
| PT-V750-768W |
800*800*1200 |
750 |
6.67*10-3 |
±5 |
0.67 |
800 |
dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The above parameters can be adjusted according to process requirements and are not used as acceptance basis. The specific technical plan and agreement shall prevail.dtxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
