model:PT-JS223
Stainless steel bright annealing furnace
Application: Stainless steel bright annealing furnace application scope: bright annealing of tool steel, die steel, ultra-high-strength steel, high-temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals and other materials
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters Of The Product
Introduction: YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Stainless steel bright annealing furnace application scope: bright annealing of tool steel, die steel, ultra-high-strength steel, high-temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals and other materials. ...YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Applications:YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Bright annealing of tool steel, die steel, ultra-high strength steel, high temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals, etc.YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Features:YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. The rotary vane pump, diffusion pump and Roots pump set achieve high vacuum to ensure the processing quality of the workpiece.YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. The heating elements are evenly arranged to ensure the uniformity of the furnace temperature.YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. Metal molybdenum heating, stainless steel insulation, and high furnace cleanlinessYmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. The touch screen interface is friendly and practical. It can display and monitor the operating status of the equipment, call, edit and store the sintering process, and has dynamic display, historical data can be recorded and exported.YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5. With safety interlock, fault diagnosis and abnormal alarm functions
YmNMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical Parameters:
| Model |
PT-JS223 (optional) |
PT-JS334 (optional) |
PT-JS446 |
PT-JS557 (optional) |
PT-JS669 (optional) |
| Heating area (mm) |
200×200×300 |
300×300×400 |
400×400×600 |
500×500×700 |
600×600×900 |
| Maximum temperature (℃) |
1350 |
1350 |
1350 |
1350 |
1350 |
| Ultimate vacuum (Pa) |
10pa, 6.7×10-3pa |
| Heating element |
Metal molybdenum belt |
| structure |
Single indoor thermal horizontal structure |
| Heating rate |
0-20℃/min |
| More specifications can be customized according to requirements |
