model:PT-JS334
Hard alloy Vacuum Brazing Furnace
Application: Application range of hard alloy brazing furnace: vacuum brazing of non-ferrous metals, stainless steel, titanium alloy, high temperature alloy, hard alloy, etc. ...
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters of the Product
Description: Application range of hard alloy brazing furnace: vacuum brazing of non-ferrous metals, stainless steel, titanium alloy, high temperature alloy, hard alloy, etc. ...It is widely used in heat treatment applications in industries, enterprises and universities.mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Application range: mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Vacuum brazing of non-ferrous metals, stainless steel, titanium alloys, high temperature alloys, hard alloys, etc.mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Product features:mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. Achieve high vacuum to ensure the quality of workpiece processingmswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. Heating elements are evenly arranged to ensure the uniformity of the furnace temperaturemswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. Metal molybdenum heating, stainless steel insulation, high furnace cleanlinessmswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. The touch screen interface is friendly and practical, and can display and Monitoring the operating status of the equipment, can call, edit and store the sintering process, and have dynamic display, historical data can be recorded and exportedmswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5. Safety interlock, fault diagnosis and abnormal alarm function
mswMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
| model |
PT-JS223 (optional) |
PT-JS334 |
PT-JS446 (optional) |
PT-JS557 (optional) |
PT-JS669 (optional) |
| Heating area (mm) |
200×200×300 |
300×300×400 |
400×400×600 |
500×500×700 |
600×600×900 |
| Heating power (Kw) |
25 |
50 |
75 |
95 |
150 |
| Maximum temperature (℃) |
1350 |
1350 |
1350 |
1350 |
1350 |
| Ultimate vacuum (Pa) |
10pa, 6.7×10-3pa |
| Heating element |
Metal molybdenum belt |
| structure |
Single indoor thermal horizontal structure |
| Heating rate |
0-20℃/min |
| More specifications can be customized according to requirements |
