model:PT-R1000

Small rotary tube furnace

Application

Detailed Parameters Of The Product

A brief description:    The small rotary furnace is mainly used for the mixed burning of powder. There are 4 lifting plates welded inside the furnace tube. The furnace tube can be rotated 360° when the instrument is running, which can increase the uniformity of powder sintering, so it is especially suitable for the sintering of lithium battery materials. Such as LiFePO4,LiMnNiO4 etc.

Main application:
    small rotary tube furnace is mainly used for the mixed firing of powders. There are 4 lifting plates welded inside the furnace tube. The furnace tube can be rotated 360° when the instrument is running, which can increase the uniformity of powder sintering, so it is particularly suitable Sintering of lithium battery materials, such as LiFePO4, LiMnNiO4, etc.

Product introduction:
    This furnace is a CE-certified inclined rotary tube furnace designed for uniform sintering of powder at high temperature; the temperature control system is adjusted by PID, and 30 steps of temperature rise and fall programs can be set, using K The type thermocouple is used for temperature measurement and control, and its temperature control accuracy can reach +/- 1℃, and it can be equipped with a precision gasification device.

Technical Parameters:

product name	Small rotary tube furnace
Shell structure	Double shell with air cooling system
Furnace material	Furnace uses alumina polycrystalline fiber
Furnace tube size approximately	Diameters of 50, 60, 80, 100, 120, 150, 200mm are optional
Heating zone	200, 300, 400mm optional
Furnace tube material	Quartz furnace tube
Maximum temperature	1000°C
Temperature control method	Intelligent 30-segment PID programmable control, with over-temperature and burnout protection functions
Flange joint	Equipped with two stainless steel vacuum flanges, mechanical pressure gauge has been installed
Sealing system	The furnace tube and flange are extruded and sealed with a silicone O-ring, which is convenient for disassembly and assembly, repeatable disassembly and assembly, and good airtightness. Vacuum and atmosphere can be evacuated during rotation.
Heating rate	0-10℃/min
Heating element	Resistance wire
Operating Voltage	AC 220/380V 50Hz
Temperature measuring element	K-type thermocouple
Vacuum	Pre-evacuated to -0.1MPa (value of vacuum pressure gauge)
Accessible atmosphere	Inert gas (slightly positive pressure)
Gasification device	Accurate gasification device can be installed as needed
Provide related accessories	Crucible tongs, high temperature gloves, thermocouple, furnace plug, manual, warranty card, etc.
After-sales service	12-month warranty and lifetime warranty (except vulnerable parts)
More specifications can be customized according to requirements
