Introduction:ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The trolley-type ceramic sintering furnace features a uniform temperature field, a double-layer heat-resistant furnace body with a surface temperature close to room temperature, and an adjustable heating rate. The furnace chamber is constructed using imported ultra-high-temperature composite fiber material using CNC technology. It offers strong thermal shock resistance, strong resistance to rapid cooling and heating, excellent corrosion resistance, and is non-slumping, crystallization-resistant, and slag-free, pollution-free, and has a long service life. The control system utilizes microcomputer intelligent regulation technology, offering PID control, fully automatic control, self-tuning capabilities, multi-stage programming, and the ability to program various heating, constant temperature, and cooling programs. It offers high temperature control accuracy, high energy efficiency, and high stability. Independent protection devices are provided for overtemperature, overpressure, overcurrent, disconnection, power failure, leakage, and short circuit. The charge table rollers are electrically retractable from the furnace body, facilitating material loading and unloading and improving work efficiency.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacOptional Features: Our independently developed control software allows the furnace to be connected to a computer, enabling remote control, furnace start-up and stop, temperature program setting and storage, historical curve viewing and printing, and more.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacApplications:ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The trolley furnace is a new type of heat treatment equipment widely used in the following areas:ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac1. Material Sintering: Used for sintering structural ceramics, functional ceramics, electronic ceramics, new ceramics, metal materials, ceramic materials, nanomaterials, new glass materials, and semiconductor materials.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac2. Metal Treatment: Used for annealing and tempering high-chromium and high-manganese steel castings, ductile iron, rollers, steel balls, carbon steel, stainless steel, and various mechanical parts.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac3. Used for growing and annealing semiconductor materials, as well as encapsulating and sintering electronic components, effectively improving the connection reliability and high-temperature resistance of electronic products.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Product Features:ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. The furnace is made of high-temperature composite fiber material through CNC technology. It has strong thermal shock resistance, good corrosion resistance, no collapse, no crystallization, no slag, and long service life.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. It is easy to operate, has accurate temperature control, and is multi-programmable. It automatically heats up, keeps warm, and cools down according to the preset program. Automatic control and operation can be achieved with one click.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. Electric in and out, convenient for loading and unloading. Stable temperature control and intelligent system can ensure the reliable quality of sintered products.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. Functions such as over-temperature alarm, over-current protection, and overload protection ensure the safe operation of the equipment and prevent equipment damage or safety accidents caused by abnormal conditions.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
| Product name |
Trolley-Type Ceramic Sintering Furnace |
| Model |
PT-MT1200 |
PT-MT1400 |
PT-MT1700 |
| Max.temperature |
1200℃ |
1400℃ |
1700℃ |
| Working temperature |
≤1100℃ |
≤1300℃ |
≤1600℃ |
| Heating element |
resistance wire |
Silicon carbon rod |
Silicon molybdenum rod |
| Thermocouple |
N type |
S type |
B type |
| Temperature control method |
PID control and self-tuning adjustment, intelligent 30-segment programmable |
| Temperature control protection |
Over-temperature and burnout protection function |
| Heating rate |
Suggest 0~10°C/min |
| Temperature control accuracy |
±1℃ |
| Chamber material |
High purity alumina refractory fiber |
| Material table in and out method |
Manual/electric (optional) |
| Furnace door structure |
The furnace door and furnace bottom are integrated, and can be opened and closed electrically or manually, making loading and unloading convenient.ZbMMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac |
| Optional Configuration |
Power off when door is opened, touch screen, remote control, computer display |
| Furnace chamber size ( width * height * depth) |
| 500*500*500mm(125L) |
500*500*700mm(175L) |
500*500*800mm(200L) |
800*800*800mm(512L) |
| 800*800*1200mm(768L) |
1000*1000*1000mm(1000L) |
1000*1000*1500mm(1500L) |
1000*1000*2000mm(2000L) |
| Other sizes can be customized according to customer needs |
