model:PT-M1400T
PT-M1400T bogie hearth furnace
Application: Electric trolley furnace consists of high quality alumina fiber brick and MoSi2 rods heating elements, the internal chamber heated from four sides, furnace bottom together with furnace door can be pushed in and out electrically. It is an ideal tool for materials annealing and sintering in your research laboratory.
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters Of The Product
5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacIntroduction:5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacThis small bogie hearth furnace is a high-performance intermittent heat treatment device designed specifically for laboratories, research institutions, and small-batch production environments. It innovatively combines the precise temperature control advantages of a box furnace with the convenient loading and unloading of a bogie hearth furnace, completely solving the pain points of traditional fixed furnace equipment, such as cumbersome operation and difficulty in handling materials.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacFeatures:5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac(1)Carbon steel outside shell & ceramic fiber lining chamber & double-layer structure with cooling fan.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(2)30 steps of programmable temperature, PID automatic temperature controller.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(3)Digital display for monitoring temperature and set temperature.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(4)Current & voltage meters for power monitoring.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(5)Unique cabinet design & easy operation.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(6)Combined aural and visual alarm for accident of over temperature & thermocouple broken, and the power supply of the heating part will cut off automatically.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(7)LCD touch screen control with 16 temperature-time curves can be saved,each temperature-time curve can be automatically set with 30 steps programmable.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(8)Furnace door can be up and down opened electrically.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(9)Furnace bottom can be pushed in and out electrically.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac Technical parameters：
| Model |
PT-M1400T |
| Chamber Structure |
Electric trailer type |
| Furnace door opening method |
Furnace door can be up and down opened electrically. |
| Furnace bottom |
Furnace bottom can be pushed in and out electrically. |
| Display |
LCD Touch screen |
| Furnace body structure |
Double layer structure with cooling fan |
| Furnace shell material |
Carbon steel |
| Limit Temp. |
1400℃ |
| Max Working Temp. |
≤ 1300℃ |
| Heating Rate |
0~20℃/Min(Suggest 0~10C/min ) |
| Thermal Control Accuracy |
+/- 1℃ |
| Inside Chamber Size |
H1200*W1000*D1000mm |
| Heating Element |
SiC rod |
| Thermal Couple |
S type |
| Chamber Material |
High purity ceramic fiber |
| Heating method |
Heating from four sides |
| Temperature Control |
•PID automatic control via SCR power control5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
•LCD touch screen control with 16 temperature-time curves can be saved,each temperature-time curve can be automatically set with 30 steps programmable.5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
•Built-in Over Temperature and Thermocouple Failure Protection. |
| Warranty |
One year warranty(not include heating element and other wear parts) |
5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Why Choose Our Bogie Hearth Furnace?5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5N3Muffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
We not only provide the equipment, but also offer a full range of services from process consultation and equipment customization to after-sales support. Our PT-MT series bogie hearth furnaces, with their superior reliability, user-friendly design, and excellent energy efficiency, have become the trusted choice for many research and industrial users processing small to medium-sized, heavy, or multi-batch materials.
