model:PT-M1700

PT-M1700 Muffle furnace with windows

Application

Detailed Parameters Of The Product

Product overview:
1. The muffle furnace has a window hole, which can be observed during combustion, which is very helpful to the experiment. In addition, the muffle furnace has a unique touch screen control system, which makes the graphical interface of the control more accurate and easy to operate.
2. The furnace or furnace chamber technology made of unique high-purity alumina fiber material has excellent thermal insulation performance, thus reducing power consumption by 30%
3. It can be equipped with computer software interface to monitor and operate the PC globally.

Technical parameters:

Model	PT-M1700
Chamber mode	Side door
display	Touch screen (LCD)
Maximum temperature	1600 degrees Celsius
Operating temperature	<= 1500 degrees Celsius
Heating rate	It recommended 0~ 10 deg.] C / min
Temperature zone	single
accuracy	+ -1 degrees Celsius
Inner cavity size	120 * 120 * 130 (mm)
Heating element	MoSi2
Thermocouple	Type B
Highest power	1.8kw
Operating Voltage	AC 208V-240V single phase, 50/60 Hz
temperature control	PID automatic control through SCR power control
Heating curve	30 steps programmable
Cabinet material	Alumina fiber
Guarantee	One year limited warranty (for wearing parts, such as heating elements Not covered by warranty)
