model:

PCD Inserts

Application

Contact us for customize send-email: info@lab-furnace.com

Detailed Parameters Of The Product

Description:
The PCD Inserts can be used in many fields including aviation, the car industry, energy equipment, and the wood and stone industry. It can be used to cut and process different materials such as aluminum,copper, aluminum/gray iron composites, as well as nonmetallic materials such as wood,chipboard,ceramics,plastic,rubber etc,where high abrasion resistance and good surface finish are requried.

Features:
1. The PCD insert meets the international standard of ISO.
2. High abrasive resistance, high processing precision, good thermal conductivity and long service life.
3. The PCD insert cutting edge is sharp, it can realize high speed cutting and hard material cutting with high work efficiency and facilitate fast clamping.
4. It can be used repeatedly, which helps to lower your processing cost.

Technical Parameter:

Insert Type	PCD Inserts
Workpiece Materials	Aluminum & Aluminum alloy	Non metal	Tungsten carbide
Cutting Speed (m/min)	200-3000	100-500	20-30
Feeding Rate (mm/rev)	0.05-0.5	0.05-0.5	0.05-0.2
Cutting Depth (mm)	0.05-1.0	0.05-1.0	0.05-0.2
