This three-zone atmosphere tube furnace has three heating zones, each with independent temperature control. It features large-size quartz furnace tubes and a long-term operating temperature of up to 950℃. The extended heating zone design accommodates processes requiring prolonged heating or complex temperature gradients (such as gradient annealing and segmented sintering). This tube furnace boasts advantages such as safety and reliability, simple operation, high temperature control accuracy, excellent heat preservation, and high furnace temperature uniformity. It can be used with various atmospheres and is widely applied in universities, research institutes, and industrial enterprises for high-temperature sintering, metal material processing experiments, quality inspection, and small-batch production.
| Product Name | Large-size three temperature zones quartz tube furnace | ||
| Product Model | PT-TG950-S100CK3 | ||
| Furnace tube outer diameter | Φ100 mm (actual size may vary) (More specifications can be customized according to customer requirements) |
||
| Furnace tube material | Quartz tube | ||
| heating zone | Three temperature zones, each with a length of 500mm + 600mm + 500mm, for a total heating zone length of 1600mm (More specifications can be customized according to customer requirements). |
||
| highest temperature | 1100℃ | ||
| Operating temperature | ≤950℃ | ||
| heating element | resistance wire | ||
| Temperature control accuracy | ±1℃ | ||
| heating rate | 0-10℃/min | ||
| Furnace body structure | 1. Employs a double-shell structure with a cooling fan installed inside the furnace body to reduce surface temperature. 2. The furnace chamber consists of furnace chamber material, insulation material, and heating elements. 3. The temperature control system comprises temperature controllers, control elements, and thermocouples. The furnace body and temperature control system are integrated, with the furnace chamber fixed to the lower casing. |
||
| Temperature testing element | N-type thermocouples, three temperature-controlled thermocouples, for more accurate temperature control. | ||
| Temperature control system | The temperature control system features touchscreen operation and artificial intelligence adjustment technology, with PID regulation, self-tuning function, and the ability to program 30 temperature rise and fall segments. 1. It uses PID temperature control, allowing for 30 temperature rise and fall segments, and has three independent temperature control systems; temperature control accuracy is ±1ºC. 2. It has over-temperature protection and thermocouple breakage protection; the furnace heating circuit automatically cuts off in case of over-temperature or thermocouple breakage. 3. It features touchscreen operation, data storage and output capabilities, and a 485 interface. |
||
| Sealing flange | 1 set | ||
| Door opening method | Manual, top-opening | ||
| Intake control | 2-channel float flow meter, flow range can be customized according to user requirements. | ||
| After-sales service | 12-month warranty, lifetime maintenance (heating elements and other randomly included accessories are not covered by the warranty). | ||
