Lab Furnace Safety & Parameters for Chemical High-Temp Synthesis

1. Introduction
Laboratory electric furnaces, as core equipment for the high-temperature synthesis of chemical samples, are widely used in catalyst preparation, new material synthesis, inorganic compound sintering, and other fields. Their operational safety is directly related to the personal safety of experimental personnel and the integrity of equipment, while the scientificity of parameter settings determines the purity, crystallinity, and reaction efficiency of sample synthesis. Combined with the particularities of chemical experiments, this article systematically sorts out the safe operation guidelines and key parameter setting specifications for laboratory electric furnaces, providing technical references for standardized laboratory operations.

2. Safe Operation Specifications for Laboratory Electric Furnaces
2.1 Pre-Operation Preparation
Equipment Inspection: Before startup, confirm that the furnace body is free of damage, the furnace chamber is clean and free of debris, and the heating elements (resistance wires, molybdenum disilicide rods, etc.) are firmly connected without oxidation or breakage; check whether safety devices such as the temperature control system, thermocouple, and emergency stop button respond normally, and ensure that the pipelines of the cooling system (such as water-cooled electric furnaces) are free of leakage and water flow is smooth.
Environmental Requirements: The experimental area should be well-ventilated, away from flammable and explosive reagents (such as ethanol, acetone) and oxidizing gases (such as chlorine, oxygen), with no standing water or obstacles on the ground; equip with emergency equipment such as dry powder fire extinguishers and fire blankets, and experimental personnel should wear personal protective equipment (PPE) such as high-temperature resistant gloves, safety goggles, and fire-resistant clothing.
Sample Pretreatment: The sample to be synthesized should be dried to a water-free state to avoid sudden vaporization of water at high temperatures leading to a sharp increase in furnace pressure; it is strictly prohibited to directly put volatile, explosive, or highly corrosive substances into the furnace chamber. If such samples need to be processed, use sealed reaction vessels and reserve pressure relief channels.

2.2 Safety Control During Operation
Temperature Rise Operation: Follow the "stepwise temperature rise" principle to avoid furnace body cracking due to thermal expansion and contraction or sample disintegration caused by rapid temperature rise. The initial heating rate is controlled at 5-10℃/min, and after the temperature rises to 500℃, it can be adjusted to 10-20℃/min according to sample characteristics; during the temperature rise process, real-time observe whether the display value of the temperature control instrument is consistent with the actual temperature of the furnace chamber. If abnormal temperature fluctuations occur, immediately stop the temperature rise and troubleshoot.
Operation Monitoring: Do not leave the operation post without authorization during the experiment, and record the temperature, time, and sample status every 30 minutes; do not open the furnace observation window. If it is necessary to confirm the sample condition, monitor through the furnace observation hole or infrared thermometer to prevent burns from high-temperature radiation.
Emergency Handling: In case of abnormal conditions such as temperature loss of control, abnormal equipment noise, or smoke, immediately press the emergency stop button, cut off the power supply and gas source, and troubleshoot after the furnace body cools naturally; in case of fire, immediately use a dry powder fire extinguisher to extinguish the fire, and it is strictly prohibited to directly extinguish the high-temperature furnace body or chemicals with water.

2.3 Post-Operation Closure
Cooling Process: After the experiment, turn off the heating switch, keep the cooling system running, and allow the furnace body to cool naturally to below 200℃ before turning off the cooling system; it is prohibited to use forced air cooling or water pouring for rapid cooling to avoid furnace body cracking and heating element damage.
Equipment Cleaning: After the furnace chamber temperature drops to room temperature, use special tools to clean sample residues and dust in the furnace chamber, keep the inner wall of the furnace chamber smooth, and avoid residual substances affecting the accuracy of the next experiment; check the joints of heating elements and thermocouples, remove oxide layers, and ensure reliable connection.
Recording and Maintenance: Completely record experimental parameters, operation processes, and equipment operation conditions, and establish an equipment maintenance file; conduct a comprehensive inspection of the electric furnace once a month, including the aging degree of heating elements, the accuracy of the temperature control system, and sealing performance, and replace damaged parts in a timely manner.

3. Parameter Setting Specifications for Laboratory Electric Furnaces
3.1 Core Parameter Setting Logic
The parameter setting for the high-temperature synthesis of chemical samples should be combined with sample characteristics (such as melting point, thermal stability, reaction activity), synthesis goals (such as crystal phase structure, particle size, reaction conversion rate), and electric furnace type (such as box furnace, tube furnace, muffle furnace), following the principles of "precise temperature control, uniform heating and cooling, and atmosphere adaptation".

3.2 Key Parameter Setting Standards
Temperature Parameters
Set Temperature: Determined according to the sample reaction requirements, with an error controlled within ±5℃; for samples requiring multi-stage reactions, set temperatures in sections, such as low-temperature pretreatment (100-300℃), high-temperature synthesis (500-1200℃), and heat preservation curing (800-1000℃).
Heat Preservation Time: Calculated based on reaction kinetic equations, generally 2-8 hours to ensure sufficient sample reaction; the temperature fluctuation during heat preservation should be controlled within ±2℃ to avoid uneven sample performance caused by temperature fluctuations.
Heating/Cooling Rate: Adjusted according to the furnace material and sample heat resistance; the heating rate of ordinary ceramic furnace electric furnaces does not exceed 20℃/min, and corundum furnaces can be increased to 30℃/min; the cooling rate does not exceed 15℃/min to prevent sample cracking due to thermal stress.
Atmosphere Parameters
Air Atmosphere: Suitable for oxidation reactions or synthesis experiments without special requirements, no additional atmosphere control is needed, and the furnace chamber should be kept ventilated.
Inert Atmosphere: Used for the synthesis of oxidizable samples (such as metal oxides, sulfides), using inert gases such as nitrogen and argon with a purity of ≥99.99% and a flow rate controlled at 0.5-2L/min to ensure that the oxygen content in the furnace chamber is below 0.1%.
Reducing Atmosphere: Suitable for reduction reactions (such as metal element preparation), using reducing gases such as hydrogen and carbon monoxide. The gas ratio (such as hydrogen-nitrogen mixture ratio of 1:9) should be strictly controlled, with a flow rate of 0.3-1L/min. At the same time, a hydrogen leakage detector should be equipped to prevent explosion risks.
Vacuum Atmosphere: Used for the synthesis of low-boiling point samples or reactions avoiding gas participation. The vacuum degree should reach 10⁻³-10⁻⁵Pa. Before heating, evacuate to the set value first, then heat to prevent air residues from affecting sample purity.
Other Auxiliary Parameters
Sample Placement: Place the sample in the center of the furnace chamber, keeping a distance of more than 5cm from the heating element to avoid local overheating; when synthesizing multiple samples simultaneously, the spacing should be no less than 3cm to ensure uniform heating.
Container Selection: Select containers according to temperature and reaction characteristics, such as high-temperature resistant ceramic crucibles, quartz boats, graphite crucibles, etc. Avoid using ordinary glass containers (which are prone to softening and cracking when the temperature exceeds 500℃); use polytetrafluoroethylene or corundum containers for corrosive samples.

3.3 Notes on Parameter Setting
For the first use or when changing sample types, conduct preliminary experiments to gradually optimize parameters such as temperature and time, avoiding sample scrapping or equipment damage due to improper parameters.
The temperature control system should be calibrated regularly (recommended once a quarter) using standard thermometers or thermocouple calibrators to ensure that the temperature display accuracy meets experimental requirements.
For equipment such as tube furnaces that require gas injection, replace the air in the furnace chamber with gas (replacement time ≥10 minutes) before heating, and do not turn off the gas until the furnace body temperature drops below 100℃ after cooling.

4. Conclusion
The safe operation and scientific parameter setting of laboratory electric furnaces are the keys to the success of high-temperature synthesis experiments of chemical samples, as well as the core requirements of laboratory safety management. Experimental personnel must strictly abide by operating specifications, be familiar with equipment performance, accurately set parameters according to sample characteristics, and strengthen daily equipment maintenance and potential safety hazard investigation to ensure safe and efficient experimental processes and stable and reliable quality of synthesized samples.
