Operation method for processing water-containing materials in a tube furnace

When a tube furnace is used to process water-containing materials, a series of steps and precautions need to be followed to ensure the safety and effectiveness of the process. Let’s take a look at how a tube furnace should process water-containing materials!

Pretreatment stage

Drying treatment

Since the moisture in the water-containing material will affect its treatment effect in the tube furnace, it must be dried first. The material can be placed in a drying oven, and the drying temperature and time can be adjusted according to the specific material and moisture content of the material. Another feasible method is to use a freeze dryer, which can effectively remove moisture while maintaining the integrity and activity of the sample, but the operation is more difficult, and attention should be paid to the freezing speed, vacuum degree and temperature of the sample.

Screening and mixing

After drying, the material may need to be screened to remove impurities and insufficiently dried particles. If there are specific needs, different types of materials can also be mixed to meet the requirements of experiments or production.

Loading and placement stage

Selecting containers

Select sample containers suitable for tube furnaces, such as ceramic boats, quartz tubes, etc. These containers must have good high temperature resistance and will not affect the treatment effect of the material. The size and shape of the container should be determined according to the amount of material and the specifications of the tube furnace.

Loading materials

Put the pretreated materials into the container to ensure that the materials are evenly distributed. If necessary, a thin layer of refractory material can be laid at the bottom of the container to prevent the materials from directly contacting the furnace.

Placement

Place the container with materials at a suitable position in the tube furnace. According to the experimental or production requirements, the container may be placed in different areas of the furnace, such as the low temperature area, the high temperature area, etc.

Operation and control stage

Set the program

According to the experimental or production requirements, set the heating program of the tube furnace, covering parameters such as heating rate, target temperature, and insulation time. The staged heating method can be used to better control the temperature change and the treatment effect of the material.

Protective atmosphere

During the treatment process, a certain protective atmosphere, such as inert gases such as nitrogen and argon, must be maintained in the tube furnace to prevent the material from being oxidized or reacting with impurities in the atmosphere. Ensure that the flow and pressure of the protective atmosphere are stable and adjust them as needed.

Temperature control

During the treatment process, the temperature of the tube furnace must be controlled to avoid excessively high or low temperatures that cause material failure. Temperature sensors such as thermocouples can be used to monitor the furnace temperature in real time and adjust it as needed.

Air flow control

The air flow in the tube furnace needs to be controlled to prevent the pipe from being blocked or the material from coming into contact with impurities accumulated in the furnace. Air flow control can be achieved by adjusting the ventilation system in the furnace or changing the flow rate of the protective atmosphere.

Subsequent processing stage

After the processing is completed, the tube furnace should be allowed to cool naturally to room temperature before sampling to prevent the sample from breaking or deforming due to a sharp drop in temperature.

Therefore, the treatment of water-containing materials in a tube furnace requires multiple stages such as pretreatment, loading and placement, operation and control, and subsequent treatment. Attention to details and safety issues must be paid at each stage to ensure the smooth progress of the treatment process and the quality of the final product. Click to learn more about tube furnaces! Or click to consult online customer service to customize various models of electric furnaces!
