Dental zirconia sintering furnace
model:PT-M1700-DL

Dental zirconia sintering furnace

    Application:  Mainly used in the crystallization and sintering of zirconia dental crowns. At the same time, it can also achieve high temperature sintering and annealing treatment for materials in the field of powder metallurgy.
Contact us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product

Description:y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac

    Dental zirconia sintering furnace is mainly used for crystallization and sintering of zirconia crowns in denture processing factoryy5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Features of zirconia sintering furnace :y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(1).Upgrading control system with touch screen for easy operatingy5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(2).Cylinder heating chamber deisgn with six pieces heating elementy5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(3).Auto lifting and downing tray for convenient products loading and pickingy5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(4).High purity heating elements and chamber materials to keep zirconia translucenty5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(5).Real time temperature monitoring with heating curve showing and temperature calibration.y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical parameters of zirconia sintering furnace :
y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
 Model PT-M1700-DL
 Chamber size 100x120mm
Working temperature 1600℃
Thermal control PID Programming PID Control
Control accuracy +/- 1℃
Heating element High Purity MoSi2
Chamber  Alumina ceramic fiber
Max. power 1800W
Working power AC110/220/440V 50/60HZ
Dimensions 530x530x820mm
Gross weight 75Kg
y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Related Accessories:y5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
 Crucible | Zirconia beads | Crucible Tong | Protective gloves | Tray | B type thermocouple | Spare Mosi2 Heating element | Mosi2 Heating element  Fixture 丨 Filling brick | Aluminum bag | Spare Aluminum bag、Fixture | Allen wrench | Power line | User Manual | Loading tabley5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Working temperature, dimensions, chamber size can be made according special requirementy5LMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
