Product overview:
Metal tube vertical tube furnace mainly uses resistance wire as heating element, adopts double-layer shell structure and 30-segment program temperature control instrument, phase-shifting trigger, thyristor control, furnace chamber adopts alumina polycrystalline fiber Material, the furnace tube is a stainless steel metal tube, the wear tube is easy to replace, has the advantages of balanced temperature field, low surface temperature, fast temperature rise and fall, and energy saving.
technical parameter:
|
product name |
Metal tube vertical tube furnace |
|
Product number |
PT-L1000 |
|
Furnace mode |
Vertical open type |
|
Furnace material |
Imported alumina refractory fiber |
|
Heating element |
High-quality resistance wire |
|
Limit temperature |
1000°C |
|
Operating temperature |
≤800℃ |
|
Heating rate |
≤15℃ |
|
Heating temperature zone |
Two temperature zones (preheating zone + high temperature zone) |
|
Total length of temperature zone |
300+300 |
|
Furnace tube material |
Custom stainless steel pipe |
|
Tube diameter |
40, 100mm... |
|
Control mode |
Multi-segment intelligent PID program temperature control, reserved communication interface |
|
Temperature measuring element |
K-type thermocouple |
|
After-sales service |
One year warranty and lifetime warranty (consumables: high temperature sealing ring, furnace tube, heating element, etc. are not covered by the warranty) |
