Desktop High Speed Vibrating Ball Mill with 50mL Alumina Jar

Desktop High Speed Vibrating Ball Mill with 50mL Alumina Jar

    Application:  Widely used in geology, minerals, metallurgy, electronics, building materials, ceramics, chemicals, light industry, medicine, environmental protection and other departments. It is an ideal equipment for scientific research, experimental production and material research.
Contact us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product
Application:zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
    MSK-SFM-3 (Updated since 7/17/13) is a compact high speed vibrating ball mill for making small quantity of powder samples at easy and fast with improved vibration design. It has higher impact energy created by three dimensional movement, e.g. rotation, vibration and oscillation with frequency up to 1200 cycles per minute withtwo year warranty. The MSK-SFM-3 can be used in either dry or wet method to mill materials and mix all kinds of solids, suspended liquids, and pastes with different sizes and materials. It is an ideal choice to make small quantity sample in material and chemical research laboratories.zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical parameters:
zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
  • External programmable timer is available as option (please see the picture below  and choose from product option)
  • one set of Zirconia Mixing Balls (4 pcs of 11.5 mm, and 4 pcs of 10 mm) are included
Power Input
  • Single phase 220V
  • 220V AC Power plug is not included.
Motor Power Comsumption 300W
Oscillation Frequency 1,200 rounds/min (Please see the video below for performance of the jar rotation)
Timing Range 0 to 120 minutes for built in mechanical timer
Maximum Feeding Capacity 1/3 of the capacity of the ball milling tank
Feeding Granularity <1mm
Discharging Granularity 0.1 micron minimum
Compliance CE Certified
Warranty Two years limited warranty with life time technical support (after July 17, 2013)
Application Notes
  • Attention: In order to achieve the best grinding effects, it is suggested to use the milling balls with diameter less than 10mm for 50ml Zirconia jar
  • Tips for choosing proper jars and millling media for milling and grinding application:
SS mixing jar is suitable for grinding various metal materialszgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
For milling the oxide material, please choose alumina/zirconia jar and media
zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
  • Attention: DO NOT USE stainless steel balls in Alumina jars to avoid contamination. Alumina jars are not covered by the warranty.
Overall Dimensions 405mm(L) x 365mm(W) x 260mm(H)
Net Weight 40 kg (88 lbs)
Shipping Dimensions 26"(L) x 26"(W) x 24"(H)
Shipping Weight 135 lbs
 zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Descriptions Qty
Main Machine   1 unit
Alumina mixing balls zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
 (4 pcs of 11.5 mm, and 4 pcs of 10 mm)
1 set
50 ml alumina jar 1 set
75mm base cushion spring  6 pcs
30mm jar cushion spring with hooks
55mm sealing gasket  1 pair
Motor driving belt  1 unit
open-end wrench  1 unit
Hex-wrench (5mm & 6mm)  1 set
Power cord (without plug)  1 unit
zgnMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
