4" Polishing Fixture for Precision with Vacuum Chuck for Fa
model:EQ-PF-4-1V

4" Polishing Fixture for Precision with Vacuum Chuck for Fa

    Application:  Widely used in geology, minerals, metallurgy, electronics, building materials, ceramics, chemicals, light industry, medicine, environmental protection and other departments. It is an ideal equipment for scientific research, experimental production and material research.
Contact us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product

Application:YZEMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
    4" Polishing Fixture for Precision with Vacuum Chuck for Faster Thinning and Polishing - EQ-PF-4-1V
YZEMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac

Technical parameters:YZEMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Features
  • Precision Polishing Jig for accurate wafer / substrate polishing and back-thinning
  • 4" Diameter sample holder vacuum chuck to take wafer or substrate up to 4"
  • Vacuum chuck can suck wafer through vacuum pump without wax and make wafer sample mounting clean, faster and flat.
  • 2 feet length vacuum tube is included to connect vacuum pump, which keep vacuum pressure during jig rotation
  • Thickness control screw fixture with resolution of 0.005 mm to limit stock remove
  • One digital micrometer is included with resolution of +/- 1 micron for more accurate control polishing remove
  • Two dead weighs are included for adjusting polishing gravity
  • This Polishing fixture can fit with, Unipol 1202 and Unipol 1502 and any precision 12" or larger polishing machine with York support to achieve automatic polishing or thinning
  • Require a vacuum pump with rate > 70 L/ min.
  • Maximum travel distance: 6.7mm
