30T Electric Powder Press Machine
model:PTD-30S

30T Electric Powder Press Machine

    Application:  Mainly used in industries such as catalysis, silicate, ceramics, batteries, superconductivity, biochemical analysis and sample preparation of new materials.
Contact us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product
Application:tSzMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
    electric pressing machine, also known as a pellet mill, is a type of mill or machine press used to create pellets from powdered material.tSzMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical parameters:tSzMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Model PTD-30S
Pressure Range 0-30T (0-31Mpa)
Integrative Structure Mainboard,Oil Pool,Oil Cylinder with no seal structure
Diameter of Oil Cylinder Chrome plated cylindersφ110mm
Max. Travel Distance of piston stroke 30mm
 Pressure Gauge Digital Pressure Gauge
Worktable Diameter 120mm
Working Space 120×120×160mm
Pressure Stability ≤1MPa/20min
weight 80kg
Machine Dimensions 360×450×490mmtSzMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
