model:PT-M1700-80LZ
Box sintering furnace
Application: enterprise laboratories and scientific research units for sample analysis and determination, precision annealing of glass and crystals, ceramics, powder metallurgy, sintering of nanomaterials, metal parts annealing, tempering and other heat treatments that require rapid heating process requirements.
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters Of The Product
Application scope: ForIdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
enterprise laboratories and scientific research units for sample analysis and determination, precision annealing of glass and crystals, ceramics, powder metallurgy, sintering of nanomaterials, metal parts annealing, tempering and other heat treatments that require rapid heating process requirements.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Product features :IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. The furnace is made of high-quality and high-purity alumina polycrystalline fiber inorganic materials formed by vacuum adsorption with Japanese technology, which has good insulation performance, durability, high tensile strength, no impurities, high purity, and energy-saving effect is significantly better than other domestic fibers. material.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. The whole furnace body adopts a double-layer inner liner structure with an air gap in the middle. Even if the furnace temperature reaches the highest, the surface of the furnace body can still be touched safely without hot feeling.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. The furnace is made of energy-saving materials, and the energy consumption of the whole machine is only 1/3 of the same traditional electric furnace, which is energy-saving and environmentally friendly.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. Furnace body is equipped with: output voltage and output current monitoring meter, the heating status of the furnace is clear at a glance.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5. With over-temperature alarm and power-off function and leakage protection measures, the operation is safe and reliable.IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
IdUMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical Parameters:
| product name |
Ceramic fiber sintering furnace |
| Product number |
PT-M1700-80LZ |
| Operating temperature |
≤1600℃ |
| Maximum temperature |
1700°C |
| Furnace material |
Alumina fiber |
| Heating element |
High quality silicon molybdenum rod |
| Heating rate |
0-20 ℃/min |
| Temperature Control System |
PID mode adjusts 30-segment programmable automatic control, temperature control accuracy: ± 1℃ |
| Temperature control protection |
With over-temperature and burnout alarm function |
| Temperature measuring element |
B-type thermocouple temperature measurement |
| Furnace size |
400*400*500mm (More specifications can be customized according to customer requirements) |
| Door opening method |
Side door |
| Operating Voltage |
AC 220V/380 50 Hz |
| heating power |
27KW |
| Provide related accessories |
1 crucible tongs, 1 pair of high temperature gloves, 1 manual, 1 certificate of warranty card |
