1700 degree box type resistance furnace
model:PT-M1700-36LZ

1700 degree box type resistance furnace

    Application:  For enterprise laboratories and scientific research units for sample analysis and determination, alumina products, powder metallurgy, and sintering of nanomaterials. Precision annealing of glass and crystals, quenching, annealing, and tempering of metal parts, etc. require heat treatment requiring rapid heating process.
Contace us for customize send-email: info@lab-furnace.com
Zhengzhou Protech Zhengzhou Protech
Detailed Parameters Of The Product
Application range:
    For enterprise laboratories and scientific research units for sample analysis and determination, alumina products, powder metallurgy, and sintering of nanomaterials. Precision annealing of glass and crystals, quenching, annealing, and tempering of metal parts, etc. require heat treatment requiring rapid heating process.

Product features :
1. The furnace is made of high-quality and high-purity alumina polycrystalline fiber inorganic materials formed by vacuum adsorption with advanced technology, which has good insulation performance, durability, high tensile strength, no impurities, high purity, and energy-saving effect is significantly better than other domestic fibers. Materials;
2. The whole furnace body adopts a double-layer inner liner structure with an air gap in the middle. Even if the furnace temperature reaches the highest, the surface of the furnace body can still be touched safely without hot feeling.
3. The furnace is made of energy-saving materials, and the energy consumption of the whole machine is only 1/3 of the same traditional electric furnace, which is energy-saving and environmentally friendly.
4. Furnace body is equipped with: output voltage and output current monitoring meter, the heating status of the furnace is clear at a glance.
5. With over-temperature alarm and power-off function and leakage protection measures, the operation is safe and reliable.

Technical Parameters:
product name High temperature sintering furnace
Product number PT-M1700-36LZ
Operating temperature ≤1600℃
Maximum temperature 1700°C
Furnace material Alumina fiber
Heating element High quality silicon molybdenum rod
Heating rate 0-20 ℃/min
Temperature Control System PID mode adjusts 30-segment programmable automatic control, temperature control accuracy: ± 1℃
Temperature control protection With over-temperature and burnout alarm function
Temperature measuring element B-type thermocouple temperature measurement
Furnace size 300*300*400mm (More specifications can be customized according to customer requirements)
Door opening method Side door
Operating Voltage AC/380 50 Hz
heating power 15KW
Provide related accessories 1 crucible tongs, 1 pair of high temperature gloves, 1 manual, 1 certificate of warranty card
