model:EQ-YLJ-40TA

40T Desktop Electric Hydraulic Laboratory Press - EQ-YLJ-40T

temperature:
- 1200
- 1400
- 1700
chamber size:

Contace us for customize send-email: info@lab-furnace.com

Detailed Parameters Of The Product

Application:
EQ-YLJ-40TA is an electric hydraulic pressing machine with pressure capability up to 40 metric tons for preparing compound or ceramic sample faster and easier. YLJ-40TA has a built-in electric hydraulic pump with automatic pressure limit switch and warning timer. It is an excellent tool for material / ceramic / chemistry laboratories to make larger pellet samples.
Technical parameters:

Name	40T Desktop Electric Hydraulic Laboratory Press - EQ-YLJ-40TA
Model	PT-EHP-60T
Normal Working Pressure Range	0~30 Metric Tons (40T Max.)
Pressure Stability	1MPa /10min
Power	Standard: 220V AC ( single phase ) 180W Optional: Please order 1000W 110V-220V transformer for using under 110V
Electric Hydraulic Pump	Pressure gauge with built in pre-stable pressure switch ( accuracy +/-0.5% FS) Pressure load will stop when pressure reach pre-settiing point
Bottom Hydraulic Cylinder Travel Distance	0 - 25 mm
Top Support Screw Adjustable Height	180 mm
Dimension of Working Space Under Frame	D1: 122mm D2: 113mm H1: 210mm H2: 180mm
Machine Dimensions	370mm(L) x 350mm(W) x 450mm(H)
Net Weight	55 Kg ( 121 lbs)
Shipping Dimensions	39"(L) x 31"(W) x 35"(H)
Weight of Shipment	185 lbs
Press Dies	Pressing dies with various diameters are available upon request at extra cost
Warranty	The pressing machine was quality inspected in USA, lifetime support is provided One year limited standard warranty (Extended warranty is available upto 5 years at extra cost)
Application Notes	Caution: Customers must always wear protection goggles during operation !!!

No.	Descriptions	Qty.
1	YLJ-40TA Laboratory press with built in hydraulic pump	1 unit
2	Gasket ring (D8.5xd1.9mm)	1 pcs
3	Machine oil 30# (40ml)	1 pcs
4	Allen hex wrench (M6, M5)	1 set
5	Wrenches (8/10#, 12/14#, 17/19#)	1 set
6	Fuse (5A/250V)	2 pcs
7	Operation m anual CD	1 pcs
