model:PT-S15KW

Split type high frequency gold melting furnace

Application

Contact us for customize send-email: info@lab-furnace.com

Detailed Parameters Of The Product

Description：
The equipment is used for precious metal melting ,with a fast speed, low wastage, stable performance;adopted quartz crucible or graphite crucible, easy operation,especially for small amount gold ,Siliver , platinum, copper, aluminum,palladium melting ,This furnace suits for laboratory test use .

A. Light weight, small size and modular design
B. IGBT inversion technology, high-efficient conversion,LC series resonance
C. Environmental protection,easy operation, low labor intensity
D. Melting rapidly, heating evenly, no oxide layer, and using timer to make sure
E. equipped with water cooling system(optional)
F. Cabinet or split type of Gold melting Induction furnace for option.

Technicial Datas :

Model	PT-S15KW
Maximum oscillating power	15KW
Maximum input current	24-30A
Input voltage	Single phases 220V 50-60HZ
Voltage range	180~240V
Output frequency	30~80KHZ
Output heat current	200A~600A
Duty cycle	80%
Cooling water desire	Water pressure≥0.2Mpa water flux >3L/min
Timing function of the S15KW
Heat current and retain current	200A~600A
Heat time,retain time,cooling time	1~99 second
Size of the generator	W20×H44×L46
Weight of the generato	18KG
